Model	VBD-024-030DD
Input Voltage	100-265V AC
Input Current	0.31~0.16A
Frequency	47/63 Hz
Output Voltage	24V DC
Output regulated Current	1.25A
Output Power	30W max
Power Factor	0.95
Dimmable	Yes (Dali Dimming)
IP Rating	IP20
Dimensions (Without Box)	180 x 60 x 35mm (7.1 x 2.3 x 1.3 in)
Dimensions (Box)	333 x 76 x 41mm (13.1 x 3 x 1.6 in)
Certification

Features:

• Input Voltage Range: 100-265V AC, compatible with a wide range of power sources.
• Input Current: 0.31~0.16A, allowing for efficient power consumption.
• Frequency: 47/63 Hz, suitable for various electrical systems.
• Output Voltage: 24V DC, providing a constant voltage for LED lighting.
• Regulated Output Current: 1.25A, delivering a stable current for LED applications.
• Maximum Output Power: 30W, suitable for low-power LED lighting setups.
• Dimming Capability: Dali dimming, enabling precise control over lighting output.
• IP Rating: IP20, suitable for indoor dry environments.
• Compact Dimensions (without box): 180 x 60 x 35mm (7.1 x 2.3 x 1.3 in), allowing for easy installation in tight spaces.
• Dimensions (with box): 333 x 76 x 41mm (13.1 x 3 x 1.6 in), including the box dimensions.
• Certification: ETL and FCC certified, ensuring safety and compliance with industry standards.
